Appendix A—Description of parameters
VARIABLE SPEED DRIVE SERIES III LIT-12012999—June 2018 www.johnsoncontrols.com
Code Modbus ID Parameter Application RO/RW
P12.2.2 1557 FB Process Data Output 2 Sel 1,2,3 RW
Use this parameter to accessing the Fieldbus Data Output Selections, parameter/monitor ID's can be
assigned to these registers and then read over the desired Fieldbus Network Word for Process Data.
Default Values for Process Data Out in Fieldbus(build table for below values)
Process Data Out1 - Output Frequency = ID 1
Process Data Out2 - Motor Speed = ID 2
Process Data Out3 - Motor Current = ID 3
Process Data Out4 - Motor Torque = ID 4
Process Data Out5 - Motor Power = ID 5
Process Data Out6 - Motor Voltage = ID 6
Process Data Out7 - DC Link Voltage = ID 7
Process Data Out8 - Active Fault Code = ID 28
See Communication Manual for more details.
P12.2.3 1558 FB Process Data Output 3 Sel 1,2,3 RW
Use this parameter to accessing the Fieldbus Data Output Selections, parameter/monitor ID's can be
assigned to these registers and then read over the desired Fieldbus Network Word for Process Data.
Default Values for Process Data Out in Fieldbus(build table for below values)
Process Data Out1 - Output Frequency = ID 1
Process Data Out2 - Motor Speed = ID 2
Process Data Out3 - Motor Current = ID 3
Process Data Out4 - Motor Torque = ID 4
Process Data Out5 - Motor Power = ID 5
Process Data Out6 - Motor Voltage = ID 6
Process Data Out7 - DC Link Voltage = ID 7
Process Data Out8 - Active Fault Code = ID 28
See Communication Manual for more details.
P12.2.4 1559 FB Process Data Output 4 Sel 1,2,3 RW
Use this parameter to accessing the Fieldbus Data Output Selections, parameter/monitor ID's can be
assigned to these registers and then read over the desired Fieldbus Network Word for Process Data.
Default Values for Process Data Out in Fieldbus(build table for below values)
Process Data Out1 - Output Frequency = ID 1
Process Data Out2 - Motor Speed = ID 2
Process Data Out3 - Motor Current = ID 3
Process Data Out4 - Motor Torque = ID 4
Process Data Out5 - Motor Power = ID 5
Process Data Out6 - Motor Voltage = ID 6
Process Data Out7 - DC Link Voltage = ID 7
Process Data Out8 - Active Fault Code = ID 28
See Communication Manual for more details.
P12.2.5 1560 FB Process Data Output 5 Sel 1,2,3 RW
Use this parameter to accessing the Fieldbus Data Output Selections, parameter/monitor ID's can be
assigned to these registers and then read over the desired Fieldbus Network Word for Process Data.
Default Values for Process Data Out in Fieldbus(build table for below values)
Process Data Out1 - Output Frequency = ID 1
Process Data Out2 - Motor Speed = ID 2
Process Data Out3 - Motor Current = ID 3
Process Data Out4 - Motor Torque = ID 4
Process Data Out5 - Motor Power = ID 5
Process Data Out6 - Motor Voltage = ID 6
Process Data Out7 - DC Link Voltage = ID 7
Process Data Out8 - Active Fault Code = ID 28
See Communication Manual for more details.
P12.2.6 1561 FB Process Data Output 6 Sel 1,2,3 RW
Use this parameter to accessing the Fieldbus Data Output Selections, parameter/monitor ID's can be
assigned to these registers and then read over the desired Fieldbus Network Word for Process Data.
Default Values for Process Data Out in Fieldbus(build table for below values)
Process Data Out1 - Output Frequency = ID 1
Process Data Out2 - Motor Speed = ID 2
Process Data Out3 - Motor Current = ID 3
Process Data Out4 - Motor Torque = ID 4
Process Data Out5 - Motor Power = ID 5
Process Data Out6 - Motor Voltage = ID 6
Process Data Out7 - DC Link Voltage = ID 7
Process Data Out8 - Active Fault Code = ID 28
See Communication Manual for more details.
