host1(config-policy-list)#mark 1 classifier-group af1-green
host1(config-policy-list)#mark 2 classifier-group af1-yellow
host1(config-policy-list)#mark 3 classifier-group af1-red
host1(config-policy-list)#mark 4 classifier-group af2-green
host1(config-policy-list)#mark 5 classifier-group af2-yellow
host1(config-policy-list)#mark 6 classifier-group af2-red
host1(config-policy-list)#mark 7 classifier-group ef-green
NOTE: For a topology-driven LSP, you have to configure and apply the classifier list
and policy list manually.
Configuration on the Transit and Egress Routers
When the tunnel is established, the JUNOSe software automatically creates an input
policy to match the EXP bits and map them to the traffic-class/color combinations
and attaches the policy to the incoming segment of the tunnel. The JUNOSe software
generates classifier list and policy list names, and creates the policy as if the following
commands were entered:
NOTE: You do not actually issue these commands; they represent the behavior
automatically performed by the router.
host1(config)#mpls classifier-list bf-packets exp 0
host1(config)#mpls classifier-list af11-packets exp 1
host1(config)#mpls classifier-list af12-packets exp 2
host1(config)#mpls classifier-list af13-packets exp 3
host1(config)#mpls classifier-list af21-packets exp 4
host1(config)#mpls classifier-list af22-packets exp 5
host1(config)#mpls classifier-list af22-packets exp 6
host1(config)#mpls classifier-list ef-packets exp 7
host1(config)#mpls policy-list mpls-exp-matching
host1(config-policy-list)#traffic-class best-effort classifier-group bf-packets
host1(config-policy-list)#traffic-class af1 classifier-group af11-packets
host1(config-policy-list)#traffic-class af1 classifier-group af12-packets
host1(config-policy-list)#traffic-class af1 classifier-group af13-packets
host1(config-policy-list)#traffic-class af2 classifier-group af21-packets
host1(config-policy-list)#traffic-class af2 classifier-group af22-packets
host1(config-policy-list)#traffic-class af2 classifier-group af23-packets
host1(config-policy-list)#traffic-class ef classifier-group ef-packets
host1(config-policy-list)#color green classifier-group af11-packets
host1(config-policy-list)#color green classifier-group af21-packets
host1(config-policy-list)#color yellow classifier-group af12-packets
host1(config-policy-list)#color yellow classifier-group af22-packets
host1(config-policy-list)#color red classifier-group af13-packets
host1(config-policy-list)#color red classifier-group af23-packets
NOTE: For a topology-driven LSP, you must configure and apply the classifier list
and policy list manually.
312 â– Example Traffic Class Configuration for Differentiated Services
JUNOSe 11.1.x BGP and MPLS Configuration Guide
