host1#show ip bgp l2vpn vpls customer1 site-id 2 block-offset 1
BGP route information for prefix 2:1
Received route learned from internal peer 2.2.2.2 (best route)
Leaked route
Route placed in IP forwarding table
Best to advertise to external peers
Address Family Identifier (AFI) is layer2
Subsequent Address Family Identifier (SAFI) is unicast
Route Distinguisher (RD) is 100:11
Original Route Distinguisher (RD) is 100:21
MPLS in-label is none
MPLS in-label block size is 0
MPLS out-label is 46
MPLS out-label block size is 20
Next hop IP address is 2.2.2.2 (metric 3)
Multi-exit discriminator is not present
Local preference is 100
Weight is 0
Origin is IGP
AS path is empty
Extended communities RT:100:1 Layer 2:19:00:0
To display only certain information for all VPLS instances (and all VPWS instances)
in the L2VPN address family, including the status of the route:
host1:pe1#show ip bgp l2vpn all fields best rd peer next-hop loc-pref
extended-communities next-hop-cost
Prefix Rd Peer Next-hop Next-hop-cost LocPrf Extended-communities
> 1:1 100:11 0.0.0.0 self 0 200 RT:100:1 Layer2:vpls:mtu=0
>m1:1 100:22 10.2.2.2 10.2.2.2 3 100 RT:100:1 Layer2:vpls:mtu=0
> 2:1 100:33 10.3.3.3 10.3.3.3 3 200 RT:100:1 Layer2:vpls:mtu=0
>m2:1 100:44 10.4.4.4 10.4.4.4 3 0 RT:100:1 Layer2:vpls:down,:mtu=0
> 3:1 100:55 10.5.5.5 10.5.5.5 3 100 RT:100:1 Layer2:vpls:mtu=0
Meaning Table 95 on page 634 lists the show ip bgp l2vpn command output fields.
Table 95: show ip bgp l2vpn Output Fields
Field DescriptionField Name
IP address of the local VE routerLocal BGP identifier
Autonomous system numberlocal AS
Version number of the local routing information baseLocal-RIB version
Version number of the forwarding information baseFIB version
634 â– Monitoring Layer 2 NLRI for VPLS Instances
JUNOSe 11.1.x BGP and MPLS Configuration Guide
