Chapter 4
Monitoring MPLS
This chapter describes the commands you can use to monitor and troubleshoot
Multiprotocol Label Switching (MPLS) on E Series routers.
NOTE: The E120 and E320 Broadband Services Routers output for monitor and
show commands is identical to output from other E Series routers, except that the
E120 and E320 router output also includes information about the adapter identifier
in the interface specifier (slot/adapter/port).
This chapter contains the following sections:
■ Setting the Baseline for MPLS Statistics on page 316
■ Clearing and Re-Creating Dynamic Interfaces from MPLS Major
Interfaces on page 319
■ Clearing and Refreshing IPv4 Dynamic Routes in the Tunnel Routing
Table on page 319
■ Clearing and Refreshing IPv6 Dynamic Routes in the Tunnel Routing
Table on page 319
■ Tracing Paths Through the MPLS User Plane on page 320
■ Monitoring ATM VCs and VPI/VCI Ranges Used for MPLS on page 320
■ Monitoring Global Call Admission Control Configuration on page 322
■ Monitoring Interfaces Configured with Traffic Engineering Bandwidth
Accounting on page 322
■ Monitoring Virtual Router Configuration on page 323
■ Monitoring IP and IPv6 Tunnel Routing Tables on page 323
■ Monitoring LDP on page 325
■ Monitoring MPLS Label Bindings on page 327
■ Monitoring LDP Graceful Restart on page 328
■ Monitoring Interfaces That are Synchronizing with LDP on page 329
■ Monitoring LDP Interfaces on page 330
■ Monitoring LDP Neighbors on page 332
■ Monitoring LDP Profiles on page 334
■ Monitoring LDP Statistics on page 335
