Learning: Enabled
Max Learn: Unlimited
Link Status Snmp Traps: Disabled
Subscriber Policy: default Subscriber
Port Count: 2
Interface Count: 1
Transport Virtual Rtr: pe1
Route Distinguisher: 1.1.1.1:10
SiteName: westford
SiteId: 1
SiteRange: 20
VPLS Route Targets
Route Target: RT:100:2 (both)
Flood Next Hop: Index 1048578
MPLS next-hop: 21, label 56, resolved by MPLS next-hop 19
MPLS next-hop: 19, resolved by MPLS next-hop 17, peer 2.2.2.2
MPLS next-hop: 17, label 82 on ATM2/0.10, nbr 10.10.10.2
Interface Port Status
------------------------- ------ ------------
ATM2/0.12 1 Up
vpls vpls2 2 Up
Connections status code:
UP = Operational
SC = Local and Remote Site Identifier Collision
EM = Encapsulation Mismatch
OR = Out of Range
DN = VC Down because Remote PE Unreachable
LD = Local Site Down
RD = Remote Site Down
AS = Max BGP AS path length exceeded
OL = No Out Label
Site State Remote PE In-label Out-label MPLS NH Idx Up-down Time
----- ----- --------------- -------- --------- ----------- ------------
2 UP 2.2.2.2 27 56 21 00:02:56
Meaning Table 99 on page 640 lists the show vpls connections command output fields.
Table 99: show vpls connections Output Fields
Field DescriptionField Name
Name of the VPLS instance for which information is displayedBridgeGroup
Bridging capability currently enabled; for a VPLS instance, this field
always displays default
Bridge Mode
Length of time, in seconds, that a MAC address entry can remain
in the forwarding table before expiring
Aging Time
Whether acquisition of dynamically learned MAC addresses is
enabled or disabled
Learning
Maximum number of dynamic MAC addresses that the VPLS
instance can learn
Max Learn
Whether SNMP link status processing is enabled or disabledLink Status Snmp Traps
Name of the subscriber policy currently in effectSubscriber Policy
640 â– Monitoring VPLS-Specific Settings
JUNOSe 11.1.x BGP and MPLS Configuration Guide
