Topology Driven LSP enabled
LSPs used for IP forwarding
for host addresses only
Additional detail is shown when RSVP-TE is enabled:
RSVP is enabled
LSRID 10.1.1.1
Re-optimization timer is 3600
Tunnel retry forever at interval 5 if route is available
Tunnel retry forever at interval 5 if no route is available
Refresh reduction is OFF
Message bundling is OFF
Egress label is non-null
Hellos are on with an interval of 10000 and miss limit of 4
Graceful restart is ON
Restart time 60000 milliseconds
Recovery time 120000 milliseconds
â– Additional detail shown when RSVP-TE graceful restart helper mode is enabled:
RSVP is enabled
...
Graceful restart is ON (helper mode)
Meaning Table 45 on page 339 lists the show mpls command output fields.
Table 45: show mpls Output Fields
Field DescriptionField Name
Status of MPLS, administratively enabled or disabled, and
configuration status
MPLS
IP address of label-switched routerLSR ID
Frequency at which LSPs are checked for better pathsRe-optimization timer
Range of platform label spaceLabel range
Retry behavior to be performed during LSP setupretry
Status of loop detection, enabled or disabledLoop Detect
This field and the following fields are displayed only when LDP is
enabled.
LDP
IP address of label-switched routerLSR ID
State of FEC deaggregation, on or offFEC Deaggregation
Type of label advertised for the LSR that is the egress router for
the prefix, explicit-null or a non-null label
Egress label
Label distribution control mode used by LDP for label distribution,
independent control or ordered control
Label distribution control
mode
Monitoring MPLS Status and Configuration â– 339
Chapter 4: Monitoring MPLS
