Table 36: show ldp Output Fields (continued)
Field DescriptionField Name
Number of out labels (received from downstream neighbor)totalOutLabels
Number of constraint-based routed LSPs set uptotalCrLSPSetup
Number of constraint-based routed LSPs deletedtotalCrLSPDeleted
Related Topics â– show ldp
Monitoring MPLS Label Bindings
Purpose Use to display label bindings from the MPLS label information base.
Action To display MPLS label bindings:
host1#show mpls binding
Frame Relay over MPLS vc-id 50001 group-id 2
In 26 neighbor 10.9.1.3
Out 27 neighbor 10.9.1.3
VLAN over MPLS vc-id 240001 group-id 2
In 22 neighbor 10.9.1.3
Out 25 neighbor 10.9.1.3
10.1.1.1/32
In 10001 neighbor 10.3.11.2
Out 20001 neighbor 10.3.11.2
10.2.2.2/32
In 10002 neighbor 10.4.12.2 stale
Out 20002 neighbor 10.4.12.2 stale
10.3.3.3/32
In 10005 neighbor 10.4.12.2 stale
Out 20003 neighbor 10.4.12.2 stale
10.4.12.0/30
In 10003 neighbor 10.5.5.2
Out 20004 neighbor 10.5.5.2
10.4.23.0/30
In 10004 neighbor 10.5.5.2
Out 20005 neighbor 10.5.5.2
NOTE: The ldp keyword and the mpls keyword display the same information.
Meaning Table 37 on page 328 lists the show ldp binding command and show mpls binding
command output fields.
Monitoring MPLS Label Bindings â– 327
Chapter 4: Monitoring MPLS
