Table 57: show mpls rsvp counters Output Fields (continued)
Field DescriptionField Name
Number of pathtear messages sent on the interfacePath Tear Sent
Number of pathtear messages received on the interfacePath Tear Rcvd
Number of resv messages sent on the interfaceResv Sent
Number of resv messages received on the interfaceResv Rcvd
Number of resverr messages sent on the interfaceResv Error Sent
Number of resverr messages received on the interfaceResv Error Rcvd
Number of resvtear messages sent on the interfaceResv Tear Sent
Number of resvtear messages received on the interfaceResv Tear Rcvd
Number of resvconf messages sent on the interfaceResv Conf Sent
Number of resvconf messages received on the interfaceResv Conf Rcvd
Number of srefresh messages sent on the interfaceSrefresh Conf Sent
Number of srefresh messages received on the interfaceSrefresh Conf Rcvd
Number of resvconf messages sent on the interfaceAck Conf Sent
Number of resvconf messages received on the interfaceAck Conf Rcvd
Number of nack objects sent on the interfaceNack Objects Sent
Number of nack objects received on the interfaceNack Objects Rcvd
Number of message bundles sent on the interfaceMsg Bundles Objects Sent
Number of message bundles received on the interfaceMsg Bundles Rcvd
Number of error messages received on the interfaceError Msgs Rcvd
Number of misordered messages received on the interfaceMisordered Messages
Number of failures to successfully send messages on the interfaceSend Failures
Number of locally triggered path messagesPath Triggers
Number of locally triggered resv messagesResv Triggers
RSVP control packets that are forwarded through the routerForwarded Pkts
Number of hello messages sentHello Sent
Number of hello messages receivedHello Rcvd
Number of acknowledgments sent in response to hello requests
received
Hello Ack Sent
Monitoring RSVP-TE Interface Counters â– 361
Chapter 4: Monitoring MPLS
