3-42 Basic DMM Operation Model 2700 Multimeter/Switch System User’s Manual
4-wire RTD temperature measurement configuration
The Alpha, Beta, Delta, and Ω at 0°C parameters for the five basic RTD types are provided
in
Table 3-5. Note that these parameters can be modified using remote programming.
The steps to configure 4-wire RTD measurements are provided in Table 3-6. After
pressing SHIFT and then SENSOR, the menu starts at step 1 to select measurement units.
Each time you press ENTER to make a selection, the menu will automatically go to the
next selection. After pressing ENTER for the last step, the instrument will return to the
normal measurement state.
NOTE As shown in Table 3-6, you can select the USER sensor type, but you cannot
change the USER parameters from the front panel. The parameters for the
USER type can only be set using remote programming (see TEMPerature:FRTD
commands in
Table 3-7).
Table 3-5
RTD parameters
Type Standard Alpha Beta Delta Ω at 0°C
PT100 ITS-90 0.00385055 0.10863 1.49990 100Ω
D100 ITS-90 0.003920 0.10630 1.49710 100Ω
F100 ITS-90 0.003900 0.11000 1.49589 100Ω
PT385 IPTS-68 0.003850 0.11100 1.50700 100Ω
PT3916 IPTS-68 0.003916 0.11600 1.50594 100Ω
Table 3-6
4-wire RTD temperature measurement configuration
Step Menu Structure Description
1 UNITS: C, F, or K Select temperature measurement units
(°C, °F, or K).
2 SENS: 4W-RTD Select the 4-wire RTD transducer.
3 TYPE: PT100, D100, F100,
PT385, PT3916, or USER
Select 4-wire RTD type.

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
