15-26 SCPI Reference Tables Model 2700 Multimeter/Switch System User’s Manual
Table 15-10
UNIT command summary
Command Description
Default
parameter
Ref SCPI
UNIT
:TEMPerature <name> Select temperature units (C, CEL, F,
FAR, or K).
C Sec 3 ✓
:TEMPerature? Query temperature units. ✓
:VOLTage Path to configure voltage units. Sec 5
[:DC] <name>
[, <clist>]
Select DCV measurement units (V or DB). V
:DB Path to set DB reference voltage:
:REFerence <n> Specify reference in volts (1e-7 to 1000). 1
:REFerence? Query reference.
[:DC]? [<clist>] Query DCV units.
:AC <name> [, <clist>] Select ACV measurement units (V or DB). V
:DB Path to set DB reference voltage.
:REFerence <n> Specify reference in volts (le-7 to 1000). 1
:REFerence? Query DB reference.
:AC? [<clist>] Query ACV units.

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
