H-14 KE2700 Instrument Driver Examples Model 2700 Multimeter/Switch System User’s Manual
Name
Manual
Reference Brief Description
Advance4 None Use Case 4 — Two scans using 7708 module:
• 40 channel DCV scan (1V range). Configuration saved in User
Setup 1.
• 20 channel Ω4 scan. Configuration saved in User Setup 2.
• Models 2700 and 2701 – 100Ω range.
• Model 2750 – 10Ω range, dry-circuit ohms enabled.
• Setup 1 or Setup 2 recalled to perform scan.
• Measurement speed (rate) – 0.1 plc.
• DCV input divider – Enabled (10MΩ input impedance).
• Filter – Disabled (no filtering).
• Buffer – Store 40 DCV reading strings, 20 Ω4 reading strings.
Buffer elements include reading only.
• Limits (DCV scan) – Limit 1 (all channels) = 20mV, Master
Latch enabled.
• Triggering – Bus control source.
• Data retrieval – SRQ if limit fails.
Advance5 None Use Case 5 — 32-channel scan using 7701 module:
• Common-side 4-wire ohms measurements (CSIDe mode).
• Dry-circuit ohms option for Model 2750.
• Install jumpers to connect Input Hi and Sense Hi directly to
DUT (common-side bus).
• Install jumpers to connect channel 35 to Sense Lo and Input Lo.
• Buffer – Store 32 reading strings. Buffer elements include
reading only.
• Triggering – Immediate control source.
• Data retrieval – SRQ when buffer full.
Table H-2 (continued)
LabVIEW examples
