H-16 KE2700 Instrument Driver Examples Model 2700 Multimeter/Switch System User’s Manual
Name
Manual
Reference Brief Description
Advance8 None Use Case 8 — 7706 module in slot 1 and 7702 module in slot 2:
• 7706 module:
• Output analog output values to analog output channels.
• Output digital output values to digital output channels.
• 7702 module:
• Scan 120 DCV channels.
• Measurement speed (rate) – 1 plc.
• Filter – Disabled (no filtering).
• Math – mX+b, m = 0.555, b = -17.778.
• Limits – Limit 1 (all channels) = 100, Limit 2 = 180.
• Buffer – Store 320 reading strings. Buffer elements include
reading, channel #, and limit code.
• Triggering – Bus control source, trigger delay 0.125 seconds.
• Data retrieval – SRQ when buffer G, H, I, and full.
Simple1 None Use Case 1 — 30-channel scan using 7708 module:
• 30 channels DCV (10V range).
• 10 channels type T thermocouple temperature.
• Measurement speed (rate) – 1 plc.
• Filter – Disabled (no filtering).
• Buffer – Store 120 reading strings. Buffer elements include
reading only.
• Triggering – Bus control source.
Simple2 None Use Case 2 — 40-channel scan using 7708 module:
• 30 channels DCV (15 on 100mV range, 15 on 10V range).
• 9 channels ACV (1V range).
• 1 channel 4-wire RTD temperature.
• Measurement speed (rate) – 1 plc.
• Filter – Disabled (no filtering).
• Buffer – Store 120 reading strings. Buffer elements include
reading only.
• Triggering – Bus control source.
Table H-2 (continued)
LabVIEW examples
