102 Keysight N9010A EXA Service Guide
Instrument Messages
-221 Settings Conflict Errors
-221 Settings conflict; Sweep
Time cannot be auto-coupled
in FFT sweeps
The sweep time for FFT sweeps is set by the calculations. So
sweep time settings cannot be adjusted.
-221 Settings conflict; Sweep
Time cannot be auto-coupled
while in Zero Span
You cannot send the remote command to set the sweep time to
auto while you are in zero span.
-221 Settings conflict; Sweep
Time cannot be set while in
FFT sweeps
The sweep time for FFT sweeps is set by the calculations. It cannot
be manually controlled.
-221 Settings conflict; Swept IF
Gain High not available when
FFT IF Gain = Manual Low
When FFT IF Gain is manually set to Low, you cannot set the Swept
IF Gain to High because that would make the Reference Level
couplings wrong in swept mode.
-221 Settings conflict; Swept LO
not available when freq mode
is Fixed
SCPI only message. The LO Mode cannot be set to Swept when the
freq mode is set to fixed. Change the freq mode away from fixed, or
perform the measurement at several fixed frequencies.
-221 Settings conflict; Swept
Type=Swept is not available
while in Gated FFT
If you have selected gated FFT then you are using the FFT sweep
type and you cannot select the swept type of sweeping.
-221 Settings conflict; System
Display Settings, Annotation
is Off
This is an override that turns off many of the annotations. This is
available as a security feature.
-221 Settings conflict; T hot
must be greater than T cold
The Tcold value set under Meas Setup/ENR/Tcold, needs to be
lower than the Thot value currently being set. Tcold is often taken
as the ambient temperature of the noise source. If using an SNS
the Tcold value may be read automatically before every sweep.
-221 Settings conflict; TG start
freq is less than 1/2 Res BW
Tracking generator uncalibrated at start frequencies below 1/2 the
current resolution bandwidth.
-221 Settings Conflict; The
parameter cannot be changed
in FAST mode
-221 Settings conflict; Trace
Math is not available while
Normalize is on
The Normalize function works by doing trace manipulation, so
trace math is not available while normalization is running.
-221 Settings conflict; Trace
smoothing with VBW not
available with Avg Detector
-221 Settings conflict; Trigger
is not available with span >
0 Hz.
-221 Settings conflict; Tx Band
Spur meas does not support
this frequency band.
The transmit band spur measurement does not support all of the
commercially available frequency bands. You need to change your
selection under Mode Setup, Radio, Band to one of the supported
bands.
