Keysight N9010A EXA Service Guide 459
Replaceable Parts
Hardware
Item Description Keysight Part Number
1 A1A1MP1 Front Frame
W1312-20108
a
2 A1A1MP2 Main Keypad Overlay N9030-80002
3 A1A1MP3 Connector Overlay E4410-80109
4a A1A1MP7 Front Frame Top Trim Strip (Use with
Option PRC, Portable)
W1312-40004
(Illustrated)
4b A1A1MP8 Front Frame Top Trim Strip (Use with
standard Bench analyzer)
W1312-40019
(Not Illustrated)
5 A1A1MP9-10 Front Frame Side Trim Strip W1312-40005
6 A1A1MP4 Front Frame Ground Spring W1312-00021
7 A1A1MP5 Braided Gasket --
8 A1A1MP6 Chromeric Gasket --
9 A1A2 Front Panel Interface Board Refer to Table 14-1
10 A1A2MP1 Speaker 9164-0453
11 A1A2MP2 Speaker Foam W1312-40016
12 A1A3 Liquid Crystal Display
Serial number ≥ MY/SG51250000 2090-0997
Serial number < MY/SG51250000 2090-1040
13 A1A4 Inverter Board (display backlight power) Serial
number < MY51250000, SG51250000
0950-4635
14 A1A5 Front Panel Daughter Board N9020-63193
15 A1MP1 Main Keypad E4410-40100
16 A1MP2 Display Keypad E4410-40101
17 A1MP9 RPG Knob W1312-40017
18 A1MP3 Frequency Label, 3.6 GHz
A1MP4 Frequency Label, 7 GHz
A1MP5 Frequency Label, 13.6 GHz
A1MP6 Frequency Label, 26.5 GHz
N9010-80008
N9010-80009
N9010-80010
N9010-80011
19 A1MP7 LCD Glass Filter 1000-1513
20 A1MP8 LCD Lens Gasket W1312-40006
21 A1MP14 Display Bracket
Serial number ≥ MY/SG51250000 W1312-00145
Serial number < MY/SG51250000 W1312-00023
22 A1MP15 Inverter Board Shield W1312-00024
