Keysight N9010A EXA Service Guide 579
Assembly Replacement Procedures
Front Frame Assembly
Item Reference Designator Description
1
A1A1 Front Frame
2
A1A1MP2
Main Keypad Overlay
b
3
A1A1MP3 Connector Overlay
4
A1A1MP7 Front Frame Top Trim Strip (Use with standard Bench
analyzer)
5
A1A1MP9-10 Front Frame Side Trim Strip
6
A1A1MP4 Front Frame Ground Spring
7
A1A1MP5 Braided Gasket
8
A1A1MP6 Chromeric Gasket
9
A1A2 Front Panel Interface Board
10
A1A2MP1 Speaker
11
A1A2MP2 Speaker Foam
12
A1A3 Liquid Crystal Display
13
A1A4 Inverter Board (display backlight power) Serial number <
MY51250000, SG51250000
14
A1A5 Front Panel Daughter Board
15
A1MP1 Main Keypad
16
A1MP2 Display Keypad
17
A1MP9 RPG Knob
18
A1MP3
A1MP4
A1MP5
A1MP6
Frequency Label, 3.6 GHz
Frequency Label, 7 GHz
Frequency Label, 13.6 GHz
Frequency Label, 26.5 GHz
19
A1MP7 LCD Glass Filter
20
A1MP8 LCD Lens Gasket
21
A1MP14 Display Bracket
22
A1MP15 Inverter Board Shield
23
A1MP10-13 Cable Clamp (Front Panel Cables)
24
A1W1 Flex Circuit, Display to Front Panel Interface Board
25
A1W2 Power Cable, Front Panel Interface Board to Inverter Board
To Next Page
