Keysight Technologies X Series Service Guide

590 Keysight N9010A EXA Service Guide
Assembly Replacement Procedures
Front Frame Assembly
Figure 15-98 LED and Display Bracket Separation
Replacement
1. Refer to Figure 15-97. Place the display bracket into position in the Front
Frame Assembly. Reconnect the flex circuit A1W1 (1) and A1W3 (2) to
the front panel interface board (4).
2. Replace the screw(3) that secures the display bracket to the Front Frame
Assembly. Torque to 9 inch-pounds.
3. Replace the front panel shield.
