Keysight Technologies X Series Service Guide

634 Keysight N9010A EXA Service Guide
Functional Tests
Test Equipment
All 10 dB Fixed Attenuator
(2 required)
Frequency: 50 MHz
VSWR: < 1.2:1
8493C Option 010 8493A
Option 010
or
8493B
Option 010
Preamp
Options
(Pxx)
30 dB Fixed Attenuator Accuracy: < 0.05 dB @ 50 MHz 11708A
Cables
All 3.5 mm (1 meter) Frequency: 10 MHz to 26.5 GHz
VSWR: < 1.4:1
Loss: < 2.0 dB
11500E 8120-4921
532, 544 2.4 mm (f) to 2.4 mm (m)
(1 meter)
Frequency: 10 MHz to 44 GHz
VSWR: < 1.55:1 at 44 GHz
Loss: < 6.0 dB
8120-6164
All Cable, BNC (3 required) 120 cm (48 in.) BNC cable 10503A
Signal Source
All Synthesized Sweeper
Frequency: 10 MHz to 44 GHz
a
Harmonic level: < − 40 dBc
Amplitude range: 10 to − 20 dBm
Frequency Accuracy: 0.02%
PSG
b
83630B,
83640B,
83650B
Power Meter
All Power Meter Power Reference Accuracy: ±1.2%
Compatible with power sensor
E4418B E4419B
All Power Sensor Frequency Range: 50 MHz to
3.66 GHz
Amplitude Range: −70 to –20 dBm
8481D 8487D
8485D
503, 507,
513
Power Sensor Frequency Range: 50 MHz to
13.66 GHz
Amplitude Range: −30 to +20 dBm
8481A
526 Power Sensor Frequency Range: 50 MHz to
26.5 GHz
Amplitude Range: −30 to +20 dBm
8485A
Analyzer
Option
Item Critical Specifications
Recommended
Keysight Model
Alternate
Keysight
Model
