Keysight N9010A EXA Service Guide 635
Functional Tests
Test Equipment
532, 544 Power Sensor Frequency Range: 50 MHz to
44 GHz
a
Amplitude Range: −30 to +20 dBm
8487A
P03 Low Power Sensor Frequency Range: 50 MHz to 3.6 GHz
Amplitude Range: –70 to –20 dBm
8481D 8485D
8487D
Pxx other
than P03
Low Power Sensor
Frequency Range: 50 MHz to 44 GHz
c
Amplitude Range: –70 to –20 dBm
8487D 8485D
Miscellaneous Equipment
All Filter, 50 MHz Low Pass Cutoff Frequency: 50 MHz
Rejection at 65 MHz: > 40 dB
Rejection at 75 MHz: > 60 dB
Rejection at 80 MHz: > 60 dB
Frequency: 10 MHz to 26.5 GHz
0955-0306
526 Power Splitter, 3.5 mm Nominal Insertion Loss: 6 dB
Tracking Between Ports: < 0.25 dB
11667B
532, 544 Power Splitter, 2.4 mm Nominal Insertion Loss: 8.5 dB
Tracking Between Ports: < 0.4 dB
11667C
503, 507,
513
Power Splitter Nominal Insertion Loss: 6 dB
Tracking Between Ports: < 0.25 dB
11667A 11667B
503, 507,
513, 526
Termination, 50Ω Type N (m) Connector
Frequency: 30 Hz to 26.5 GHz
909A Option 012
532, 544 Termination, 50Ω 2.4 mm (f) Connector
Frequency: 30 Hz to 50 GHz
85138B
a. Maximum frequency equal to or greater than the maximum frequency of the EXA.
b. PSG model numbers: E8244A, E8254A, E8247C Option 520, E8247C Option H31 or 540, E8257D Option 520,
E8257D Option 550, E8257D Option 567, E8267D Option 544.
c. Maximum frequency equal to or greater than the maximum frequency of the preamplifier option.
Analyzer
Option
Item Critical Specifications
Recommended
Keysight Model
Alternate
Keysight
Model
