Keysight N9010A EXA Service Guide 95
Instrument Messages
-221 Settings Conflict Errors
-221 Settings conflict; Antenna
Unit is only available when
antenna Correction is on
These special units only apply when you are doing antenna
measurements with corrections enabled.
-221 Settings conflict; Band is
not available when Mixer
Type is Preselected
The K, E, W, F, D, G, Y, J band functionality is not available if the
selected Mixer Type is Preselected.
-221 Settings conflict; BTS gain
is not available in this
Mode
Base Transceiver Station gain correction is not available in some
Modes, or in some measurements (for example, the SA
measurement).
-221 Settings conflict;
Calibration cannot be
performed without valid ENR
data
The cal ENR table has no values in it, and hence the cal cannot be
performed. Correct by either populating the cal ENR table, set ENR
mode to Spot, or set the ‘Use Meas Table Data for Cal’ to ‘On’.
-221 Settings conflict;
Cancellation is not
available while measuring
DANL floor.
Phase Noise cancellation does not make sense when measuring
the DANL Floor, so for this reason it has been disabled
-221 Settings conflict;
Cancellation Ref trace has
no data.
When performing phase noise cancellation, you need to supply a
reference trace that will be used to cancel out the background
noise of the analyzer. The reference trace must be in Reference
(View) mode, and selected by the Ref Trace parameter under the
Cancellation menu
-221 Settings Conflict;
Cancellation trace has
different X-Scale
Reference trace for the cancellation has a different range of X-axis
against the target trace
-221 Settings conflict; Cannot
optimize while user cal in
progress
Optimize Preselector cannot be performed while a user cal is in
progress. The user cal performs an optimize preselector prior to
taking the noise source on/off level results for the cal data.
-221 Settings conflict; Carrier
freq not allowed with BMT.
(Bottom/Middle/Top only)
The transmit band spur measurement only allows bottom (B),
middle (M), and top (T) channel frequencies for each supported
frequency band. The carrier frequency must be set to the bottom,
middle or top frequency of the current frequency band.
-221 Settings Conflict; Code
channel duplication
This error is reported when the given code channel overlaps other
code channel
-221 Settings conflict; Command
is incompatible with band
pair marker
Using remote commands, you have tried to adjust the start or stop
frequency of a span pair marker. You can only adjust the center
and span.
-221 Settings conflict;
Continuous Peak is not
available with Fixed marker
The continuous peak feature cannot be used with a marker that is
fixed. By definition that marker value cannot change.
-221 Settings conflict;
Continuous Peak is not
available with Signal Track
on
The continuous peak feature cannot be used while you are also
using the signal tracking function.
