96 Keysight N9010A EXA Service Guide
Instrument Messages
-221 Settings Conflict Errors
-221 Settings conflict;
Corrections with different
antenna units not allowed
When a correction with antenna units is turned on, that is the only
unit allowed. You can have two sets of antenna corrections turned
on, but only if they have the same units.
-221 Settings conflict; Desired
preamp setting is not
available
Does this really exist? If so, what does it really mean?
-221 Settings conflict;
Destination trace for Trace
Math cannot be a trace
operand
The resulting trace data (from doing a trace math function) cannot
be put into the any of the traces that are being used by the math
operation.
-221 Settings conflict; Downconv
only available when DUT is
Amplifier
SCPI only message. The System Downconverter can only be set to
‘On’ when the DUT type is amplifier. Change DUT type to Amplifier
if the System Downconverter is required.
-221 Settings conflict; EDGE EVM
only supports EDGE TCH burst
type.
-221 Settings conflict;
Electronic attenuator is
disabled
You are using the mechanical attenuator, and have not enabled the
electronic attenuator. You cannot set the value of the electronic
attenuator because it automatically sets/changes when enabled.
-221 Settings conflict;
Electronic attenuator is not
available above 3.6 GHz
The maximum frequency of the electronic attenuator is 3.6 GHz.
This is because of switching capacitance.
-221 Settings conflict;
Electronic attenuator
unavailable in current state
-221 Settings conflict;
Electronic attenuator
unavailable with Preamp on
The internal preamp is on. Electronic attenuator cannot be used
while you are using the internal preamp.
-221 Settings Conflict; FAST
method can only be used
while Radio Std is W-CDMA
-221 Settings conflict; Feature
not supported for this
measurement.
Some functionality is available in one measurement, but not in
another. (See the measurements under the Meas key.) This error
occurs if you send a SCPI command or push a gray-out key that is
not available in the current selected measurement.
-221 Settings conflict; FFT IF
Gain High not available when
Swept IF Gain = Manual Low
When Swept IF Gain is manually set to Low, you cannot set the FFT
IF Gain to High because that would make the Reference Level
couplings wrong in FFT mode.
-221 Settings conflict; FFT
method is unavailable for
level gating
If you are using level gating, you cannot select the FFT Gate
Method.
-221 Settings conflict; FFT sweep
type is not available while
in Gated LO
The gated LO function turns the LO on and off as it sweeps. So the
FFT sweep type is not available if you have selected gated LO.
