Keysight EXA N9010A User Manual

12 Disturbance Analyzer Measurement
AMPTD Y Scale
AMPTD Y Scale
Accesses a menu that enables you to control the amplitude parameters.
Key Path
Front-panel key
Notes . Front panel only.
Initial S/W Revision A.14.00
Reference Level
Specifies the amplitude represented by the topmost graticule line.
Key Path
AMPTD/Y Scale
Remote Command
:DISPlay:DANalyzer:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:RLEVel <real>
:DISPlay:DANalyzer:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:RLEVel?
Example DISP:DAN:VIEW:WIND:TRAC:Y:RLEV 80 dBuV
DISP:DAN:VIEW:WIND:TRAC:Y:RLEV?
Couplings Ref level is always auto coupled to limit so that limit line is always in the center of graph.
Preset 106.99 dBuV
State Saved Saved in instrument state
Min RefLevelMin = –63.01dBuV + RefLevelOffset - ExtGain.
Max RefLevelMax = 206.99 dBuV + RefLevelOffset - ExtGain
Default Unit Depends on the current selected Y axis unit
Initial S/W Revision A.14.00
Scale/ Div
Specifies the units per division of vertical scale in logarithmic display.
Key Path
AMPTD Y Scale
Remote Command
:DISPlay:DANalyzer:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:PDIVision <rel_
amptd>
:DISPlay:DANalyzer:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:PDIVision?
Example DISP:DAN:VIEW:WIND:TRAC:Y:PDIV 5 dB
DISP:DAN:VIEW:WIND:TRAC:Y:PDIV?
Preset 10.00 dB
State Saved Saved in instrument state
Min 0.10 dB
Max 20.00 dB
Initial S/W Revision A.14.00
EMI Receiver Mode Reference 1031
