9 Strip Chart Measurement
AMPTD Y Scale
Example UNIT:POW DBUAM
Dependencies Grayed out if no Amplitude Correction with an Antenna Unit is on.
Readback dBµA
Initial S/W Revision A.11.00
dBpΤ
Sets the amplitude unit for the selected amplitude scale (log/lin) to dBpT. This is an antenna unit, and this
key is grayed out unless a Correction with this Antenna Unit selected is ON. If this is the case, all of the
other Antenna Units are grayed out.
Key Path
AMPTD Y Scale, Y Axis Unit, Antenna Unit
Example UNIT:POW DBPT
Dependencies Grayed out if no Amplitude Correction with an Antenna Unit is on.
Readback dBpT
Initial S/W Revision A.02.00
dBG
Sets the amplitude unit for the selected amplitude scale (log/lin) to dBG. This is an antenna unit, and this
key is grayed out unless a Correction with this Antenna Unit selected is ON. If this is the case, all of the
other Antenna Units are grayed out.
Key Path
AMPTD Y Scale, Y Axis Unit, Antenna Unit
Example UNIT:POW DBG
Dependencies Grayed out if no Amplitude Correction with an Antenna Unit is on.
Readback dBG
Initial S/W Revision A.02.00
None
This is selected if no Antenna Unit is currently on, however you cannot actually set this value, since it is
always grayed out. The key is included simply to provide an indication on the Readback line of the Antenna
Unit key when there is no Antenna Unit selected.
Key Path
AMPTD Y Scale, Y Axis Unit, Antenna Unit
Readback “None”
Initial S/W Revision A.11.00
618 EMI Receiver Mode Reference
