8 Frequency Scan Measurement
Trace/ Detector
Couplings Selecting a detector for a trace (pressing the key or sending a [:SENS]:FSC:DET:TRAC command) puts
Update On and Display On for that trace, even if that detector was already selected.
Initial S/W Revision A.07.00
Negative Peak
This sets the detector for the currently selected trace to Negative Peak. For each bucket (interval) in the
trace, Negative Peak detection displays the lowest sample within the bucket. The Negative peak detection
is similar to peak detection, but selects the minimum video signal.
Key Path
Trace/Detector, Detector
Example FSC:DET:TRAC2 NEG Sets the detector to peak for trace 2.
Couplings Selecting a detector for a trace (pressing the key or sending a [:SENS]:FSC:DET:TRAC command) puts
Update On and Display On for that trace, even if that detector was already selected.
Initial S/W Revision A.07.00
Copy/Exchange
This menu lets you copy any trace to any other trace, or exchange any trace with any other trace.
The X Axis settings and domain of a trace go with it when it is copied or exchanged.
Key Path
Trace/Detector
Initial S/W Revision A.07.00
From Trace
Selects the trace to be copied to or exchanged with the To Trace.
Key Path
Trace/Detector, Copy/Exchange
Preset 1
State Saved Saved in instrument state.
Initial S/W Revision A.07.00
To Trace
Selects the trace to be copied from or exchanged with the From Trace.
Key Path
Trace/Detector, Copy/Exchange
Preset 2
EMI Receiver Mode Reference 585
