9 Strip Chart Measurement
AMPTD Y Scale
Preset dBm for log scale, V for linear. The true ‘preset’ value is dBm, since at preset the Y Scale type is set to
logarithmic.
State Saved Saved in instrument state
Readback line 1-of-N selection
Initial S/W Revision Prior to A.02.00
Modified at S/W Revision A.02.00, A.04.00, A.11.00
dBm
Sets the amplitude unit for the selected amplitude scale (log/lin) to dBm.
Key Path
AMPTD Y Scale, Y Axis Unit
Example UNIT:POW DBM
Dependencies Grayed out if an Amplitude Correction with an Antenna Unit is ON.
Readback dBm
Initial S/W Revision Prior to A.02.00
Modified at S/W Revision A.02.00
dBmV
Sets the amplitude unit for the selected amplitude scale (log/lin) to dBmV.
Key Path
AMPTD Y Scale, Y Axis Unit
Example UNIT:POW DBMV
Dependencies Grayed out if an Amplitude Correction with an Antenna Unit is ON.
Readback dBmV
Initial S/W Revision Prior to A.02.00
Modified at S/W Revision A.02.00
dBmA
Sets the amplitude unit for the selected amplitude scale (log/lin) to dBmA.
Key Path
AMPTD Y Scale, Y Axis Unit
Example UNIT:POW DBMA
Dependencies Grayed out if an Amplitude Correction with an Antenna Unit is ON.
Readback dBmA
Initial S/W Revision Prior to A.02.00
Modified at S/W Revision A.02.00
614 EMI Receiver Mode Reference
