Keysight EXA N9010A User Manual

1 About the Analyzer
Window Control Keys
The selected window is local to each Measurement. Each Measurement remembers which window is
selected. The selected window for each Measurement is remembered in Mode state.
When this key is pressed in Help Mode, it toggles focus between the table of contents window and the
topic pane window.
Full Screen
When Full Screen is pressed the measurement window expands horizontally over the entire instrument
display. The screen graticule area expands to fill the available display area.
It turns off the display of the softkey labels, however the menus and active functions still work. (Though it
would obviously be very hard to navigate without the key labels displayed.) Pressing Full Screen again
while Full Screen is in effect cancels Full Screen.
Note that the banner and status lines are unaffected. You can get even more screen area for your data
display by turning off the Meas Bar (in the Display menu) which also turns off the settings panel.
Full Screen is a Meas Global function. Therefore it is cancelled by the Preset key.
Key Path
Display
Remote Command
:DISPlay:FSCReen[:STATe] OFF|ON|0|1
:DISPlay:FSCReen[:STATe]?
Preset Unaffected by Preset but set to Off by Restore Misc Defaults or shutdown and restart
State Saved Not saved in instrument state.
Backwards
Compatibility SCPI
:DISPlay:MENU[:STATe] OFF|ON|0|1
This emulates ESA full screen functionality, which is the same as the FSCReen command in PSA
except that the sense of on/off is reversed (that is, OFF means the menus are OFF, so Fullscreen is
ON) and the default is ON (meaning Fullscreen is OFF).
Backwards Compatibility
Notes
In ESA/PSA, Full Screen was turned on with a softkey, so pressing any other key turned Full Screen
off. In the X-Series, because a hardkey is provided to turn this function on and off, pressing any
other key no longer turns off Full Screen
Initial S/W Revision Prior to A.02.00
Display Enable (Remote Command Only)
Turns the display on/off, including the display drive circuitry. The backlight stays lit so you can tell that the
instrument is on. The display enable setting is mode global. The reasons for turning the display off are
three:
• To increase speed as much as possible by freeing the instrument from having to update the display
• To reduce emissions from the display, drive circuitry
• For security purposes
If you have turned off the display:
56 EMI Receiver Mode Reference
