11 APD Measurement
AMPTD Y Scale
dBµV/m
This sets the amplitude unit for the selected amplitude scale to dBµV/m. This is an antenna unit, and this
key is grayed out unless a Correction with this Antenna Unit selected is ON. If this is the case, all of the
other Antenna Units are grayed out.
Key Path
AMPTD Y Scale, Amplitude Unit, Antenna Unit
Example UNIT:APD:POW DBUVM
Dependencies Grayed out if no Amplitude Correction with an Antenna Unit is on.
Readback dBµV/m
Initial S/W Revision A.13.00
dBµA/m
This sets the amplitude unit for the selected amplitude scale to dBµA/m. This is an antenna unit, and this
key is grayed out unless a Correction with this Antenna Unit selected is ON. If this is the case, all of the
other Antenna Units are grayed out.
Key Path
AMPTD Y Scale, Amplitude Unit, Antenna Unit
Example UNIT:APD:POW DBUAM
Dependencies Grayed out if no Amplitude Correction with an Antenna Unit is on.
Readback dBµA/m
Initial S/W Revision A.13.00
dBµA
This sets the amplitude unit for the selected amplitude scale to dBµA. This is an antenna unit, and this key
is grayed out unless a Correction with this Antenna Unit selected is ON. If this is the case, all of the other
Antenna Units are grayed out.
Key Path
AMPTD Y Scale, Amplitude Unit, Antenna Unit
Example UNIT:POW DBUAM
Dependencies Grayed out if no Amplitude Correction with an Antenna Unit is on.
Readback dBµA
Initial S/W Revision A.13.00
dBpΤ
This sets the amplitude unit for the selected amplitude scale to dBpT. This is an antenna unit, and this key
is grayed out unless a Correction with this Antenna Unit selected is ON. If this is the case, all of the other
Antenna Units are grayed out.
904 EMI Receiver Mode Reference
