8 Frequency Scan Measurement
Marker Function
Key Path
Meas Setup, Detectors (Measure)
Remote Command
[:SENSe]:FSCan:FINal:DETector[1]|2|3:LDELta <limit Num>
[:SENSe]:FSCan:FINal:DETector[1]|2|3:LDELta?
Example :FSC:FIN:DET3:LDEL 2 Set limit line 2 to be used by detector 3.
Notes Not affected by Mode Preset, preset by Restore Mode Defaults.
Dependencies This key is grayed out during final measurement. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
Preset
1|1|1
State Saved Saved in instrument state.
Range
1|2|3|4|5|6
Initial S/W Revision A.07.00
Center Presel On/Off
Controls the automatic centering of the preselector for the Measure at Marker function.
When Center Presel is On, the first step in performing the Measure at Marker function is to perform a
Presel Center. This is not performed if the microwave preselector is off, or the selected marker’s frequency
is below Band 1. If the function is not performed, no message is generated.
Key Path
Marker Function
Remote Command
:CALCulate:FSCan:MAMarker:PCENter ON|OFF|1|0
:CALCulate:FSCan:MAMarker:PCENter?
Example CALC:FSC:MAM:PCEN ON
Dependencies Blank in some non MXE instruments that do not include a preselector, such as MXA with option 503.
If a SCPI command is sent to these instruments, it is accepted without error, and the query always
returns 0.
Preset ON
State Saved Saved in instrument state
Range ON|OFF
Initial S/W Revision A.07.00
Marker Zoom
Zooms the graticule display at the selected marker to10% of current span.
Key Path
Marker Function
Remote Command
:CALCulate:FSCan:MARKer[1]|2|...|12:FUNCtion:ZOOM
Example CALC:FSC:MARK2:FUNC:ZOOM Perform marker zoom at Marker 2.
422 EMI Receiver Mode Reference
