12 Disturbance Analyzer Measurement
Marker
Example :CALC:DAN:MARK:AOFF
Couplings Sets the selected marker to 1.
Initial S/W Revision A.14.00
Marker X Axis Value (Remote Command Only)
Sets the marker X Axis value in the current marker X Axis Scale unit. It has no effect if the control mode is
Off, but is the SCPI equivalent of entering an X value, if the control mode is Normal or Delta.
Key Path
Marker, Select Marker
Remote Command
:CALCulate:DANalyzer:MARKer[1]|2|...|12:X <real>
:CALCulate:DANalyzer:MARKer[1]|2|...|12:X?
Example CALC:DAN:MARK3:X 0
CALC:DAN:MARK3:X?
Notes If no suffix is sent, it will use the fundamental units for the current marker X Axis Scale. If a suffix is
sent that does not match the current marker X Axis Scale unit, an “Invalid suffix” error will be
generated.
The query returns the marker’s absolute X Axis value if the control mode is Normal, or the offset from
the marker’s reference marker, if the control mode is Delta. The query is returned in the
fundamental units for the current marker X Axis scale: seconds. If the marker is off the response is
not a number (NAN).
Preset 9.91E+37
State Saved No
Initial S/W Revision A.14.00
Marker Y Axis Value ( Remote Command Only )
Returns the marker Y Axis value in the current marker Y Axis unit.
Remote Command
:CALCulate:DANalyzer:MARKer[1]|2|...|12:Y?
Example CALC:DAN:MARK11:Y?
Notes The query returns the marker Y-axis result. If the marker is Off the response is 9.91E+37
State Saved No
Initial S/W Revision A.14.00
EMI Receiver Mode Reference 1043
