8 Frequency Scan Measurement
Meas Setup
Preset ON
State Saved Saved in instrument state.
Range On|Off
Initial S/W Revision A.07.00
Comment
Sets an ASCII comment field for each signal in list, which will be shown in the “Comment” column of the
signal list. This value will be stored in the signal list exported file.
Key Path
Meas Setup, Signal List
Remote Command
[:SENSe]:FSCan:SLISt:COMMent <integer>,“string”
[:SENSe]:FSCan:SLISt:COMMent? <integer>
Example :FSC:SLIS:COMM 2,“unknown”
Dependencies This key is grayed out when a scan sequence is running. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
Preset “” (null String), not affected by Mode Preset, preset by Restore Mode Defaults.
State Saved Saved in instrument state.
Initial S/W Revision A.07.00
Step Control
Specifies the step control used for the scan table. If Step Size & Dwell Time is selected, the Step Size and
Dwell Time keys will appear in the Scan Table. Otherwise, the Scan Points and Scan Time keys will be
shown.
Key Path
Meas Setup
Remote Command
[:SENSe]:FSCan:SCAN:CONTrol SDWell|STPoints
[:SENSe]:FSCan:SCAN:CONTrol?
Example FSC:SCAN:CONT SDW Select Step and Dwell
FSC:SCAN:CONT?
Notes SDWell = Step Size & Dwell Time
STPoints = Scan Time & Points
Dependencies This key is grayed out during multi range scanning. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict; Function not available while running multirange scan” warning.
This key is grayed out during final measurement. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
This key is grayed out during a Time Domain Scan. If the grayed out key is pressed, an advisory
EMI Receiver Mode Reference 451
