5 Mode Functions
Mode
89601 VSA
Selecting the 89601 VSA mode will start the 89600 VSA software. The 89600 VSA software is powerful,
PC-based software, offering the industry's most sophisticated general purpose and standards specific
signal evaluation and troubleshooting tools for R&D engineers. Even for proprietary and non-standard
signals in SATCOM or MILCOM applications, you can make signal quality measurements with customized
IQ constellation. Reach deeper into signals, gather more data on signal problems, and gain greater
insight.
• Over 35 general-purpose analog and digital demodulators ranging from 2FSK to 4096QAM
• Flexible and custom IQ and OFDM signal analysis for single carrier
• Standards specific modulation analysis including:
−Cellular: GSM/EDGE, cdma2000, W-CDMA, TD-SCDMA, LTE(FDD/TDD),
−LTE-Advanced and more
−Wireless networking: 802.11a/b/g, 802.11n, 802.ac, 802.16 WiMAX (fixed/mobile), WiSUN (MR-FSK
PHY)
−RFID
−Digital satellite video and other satellite signals, radar, LMDS
−Up to 400K bin FFT, for the highest resolution spectrum analysis
−A full suite of time domain analysis tools, including signal capture and playback, time gating, and
CCDF measurements
−20 simultaneous trace displays and the industry's most complete set of marker functions
−Easy-to-use Microsoft ® Windows ® graphical user interface
For more information see the Agilent 89600 Series VSA web site at www.agilent.com/find/89600vsa
To learn more about how to use the 89600 VSA running in the X-Series, after the 89600 VSA software is
running, open the 89600 VSA Help and open the "About Agilent X-Series Signal Analyzer with 89600 VSA
Software" help topic.
Key Path
Mode
Example INST:SEL VSA89601
INST:NSEL 101
Initial S/W Revision Prior to A.02.00
Application Mode Number Selection (Remote Command Only)
Select the measurement mode by its mode number. The actual available choices depend upon which
applications are installed in your instrument. The modes appear in this table in the same order they appear
in the Mode menu (if the order is not changed by the Configure Applications utility found in the System,
Power On menu). See "Detailed List of Modes" on page 232 for Mode details.
EMI Receiver Mode Reference 227
