11 APD Measurement
Recall
Remote Command
:MMEMory:LOAD:LIMit:DDIRectory USER|PRELoaded
Example :MMEM:LOAD:LIM:DDIR USER Select user
:MMEM:LOAD:LIM:DDIR?
Notes USER = User
PRELoaded = Preloaded
Preset PRELoaded
State Saved Saved in instrument state.
Range User| Preloaded
Readback “User”| “Preloaded”
Initial S/W Revision A.13.00
Signal List
This key selects Signal List as the data type to be imported. The next step is to select the Open key in the
Import Data menu. Importing a Signal List always replaces the data with the data that is already in the
signal list.
Key Path
Recall, Data
Remote Command
:MMEMory:LOAD:ALISt <filename>
Example MMEM:LOAD:ALIS "myAPDSignalList2.csv" imports the Signal List from the file
myAPDSignalList2.csv in the current path. The default path is My
Documents\EMI\data\APD\SignalList.
Notes If the file is empty, error –250.3005 is reported. If the file does not exist error –256 is reported. If
there is a mismatch between the file and the destination data type, an error is reported. –250.3003.
Then you are returned to the Import Data menu and the File Open dialog goes away.
Status Bits/OPC
dependencies
Sequential - aborts the current measurement
Initial S/W Revision A.13.00
Open…
When you press “Open”, the analyzer brings up a Windows dialog and a menu entitled “File Open.” This
menu allows you to navigate to the various fields in the Windows dialog without using a keyboard or
mouse. The Tab and Arrow keys can also be used for dialog navigation.
See "From File…" on page 1083in Recall, State, for a full description of this dialog and menu.
Key Path
Recall, Data
Notes The key location is mode-dependent and will vary.
Brings up Open dialog for recalling a <mode specific> Save Type
Initial S/W Revision Prior to A.02.00
EMI Receiver Mode Reference 975
