8 Frequency Scan Measurement
Meas Setup
SCAN5:INP:GAIN?
Notes This command is included for ESU compatibility. The suffix [1]|2 of SENSe node is irrelevant to the
measurement, they are added solely for remote language compatibility.
ON is aliased to :SCAN:POW:GAIN ON; :SCAN:POW:GAIN:BAND LOW for the selected range.
OFF is aliased to :SCAN:POW:GAIN OFF for the selected range.
Dependencies This key is grayed out when a scan sequence is running except during single range scanning. If the
grayed out key is pressed, an advisory message is generated. If the equivalent SCPI command is sent,
this same message is generated as part of a “–221, Settings conflict” warning.
Preset OFF
State Saved Saved in instrument state.
Backwards
Compatibility SCPI
:SENSe1|SENSe2:SCAN[1]|2|...|10:INPut:GAIN[:STATe]
Initial S/W Revision A.07.00
Autorange
When autorange is set to on, the attenuation will be increased automatically when an overload is detected
during a scan.
Key Path
Meas Setup, Scan Table
Remote Command
[:SENSe]:FSCan:SCAN[1]|2|...|10:INPut:ATTenuation:AUTO ON | OFF | 1 | 0
[:SENSe]:FSCan:SCAN[1]|2|...|10:INPut:ATTenuation:AUTO
Example :FSC:SCAN8:INP:ATT:AUTO 1 Turn on Auto range for Range 8
:FSC:SCAN8:INP:ATT:AUTO?
Dependencies This key is grayed out when a scan sequence is running. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
Preset OFF
State Saved Saved in instrument state.
Backwards
Compatibility SCPI
:SENSe1|SENSe2:SCAN[1]|2|...|10:INPut:ATTenuation:AUTO
[:SENSe]:SCAN[1]|2|...|10:INPut:ATTenuation:AUTO
Backwards Compatibility
SCPI Notes
This command above is included for ESU compatibility. The suffix [1]|2 and [1]|2|...|10 are irrelevant to
the measurement, they are added solely for remote language compatibility.
Initial S/W Revision A.07.00
Auto Preamp
When on, the Int Premp will be considered in the autorange procedure when performing a scan.
Key Path
Meas Setup, Scan Table
EMI Receiver Mode Reference 467
