Page #466 background image
8 Frequency Scan Measurement
Meas Setup
[:SENSe]:FSCan:SCAN[1]|2|...|10:POWer:GAIN[:STATe]?
Example FSC:SCAN4:POW:GAIN ON Turn on Internal Preamp of Range 4.
FSC:SCAN4:POW:GAIN?
Dependencies Preamp is not available on all hardware platforms. If the preamp is not present or is unlicensed, the
key is not shown.
This key is grayed out during multi range scanning. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict; Function not available while running multirange scan” warning.
This key is grayed out during final measurement. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
Preset OFF
State Saved Saved in instrument state.
Range On|Off
Initial S/W Revision A.07.00
Key Path
Meas Setup, Scan Table
Remote Command
[:SENSe]:FSCan:SCAN[1]|2|...|10:POWer:GAIN:BAND LOW|FULL
[:SENSe]:FSCan:SCAN[1]|2|...|10:POWer:GAIN:BAND?
Example FSC:SCAN3:POW:GAIN:BAND LOW Set Range 3 to Low band Preamp.
FSC:SCAN3:POW:GAIN:BAND?
Dependencies Preamp is not available on all hardware platforms. If the preamp is not present or is unlicensed, the
key is not shown.
If a POW:GAIN:BAND FULL command is sent when a low band preamp is available, the preamp band
parameter is set to LOW instead of FULL, and an Option not installed message is generated.
This key is grayed out during multi range scanning. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict; Function not available while running multirange scan” warning.
This key is grayed out during final measurement. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
Preset LOW
State Saved Saved in instrument state.
Range Low Band|Full Range
Initial S/W Revision A.07.00
Remote Command
[:SENSe]:SCAN[1]|2|...|10:INPut:GAIN[:STATe] ON|OFF|1|0
[:SENSe]:SCAN[1]|2|...|10:INPut:GAIN[:STATe]?
Example SCAN5:INP:GAIN ON Turn on low band preamp in Range 5.
466 EMI Receiver Mode Reference
