9 Strip Chart Measurement
Save
Using the C: drive is strongly discouraged, since it runs the risk of being overwritten during an
instrument software upgrade.
Both single and double quotes are supported for any filename parameter over SCPI.
Dependencies Traces cannot be recalled from a trace file that was saved with ALL traces selected.
Readback 1|2|3|All
Status Bits/OPC
dependencies
Sequential - waits for previous measurement to complete
Initial S/W Revision Prior to A.02.00
Frequency Scan Trace File Content
The following file example shows the Trace file content in Excel for one trace.
Trace
EMI:FSCAN
A.07.00 N9020A
526 EA3 B25 P26 PFR 1
Preselector On
Scan Type Smooth
Number of scans 1
Y Axis Unit dBuV
Ref Level Offset 0 dB
Coupling AC
Input Z Correction 50 ohm
Data
Trace 1
Detector Peak
30000000 –91.67179747
30060002.47 –91.73843172
30120004.95 –88.07746798
30180007.42 –90.05428387
30240009.9 –86.55925246
30300012.37 –87.6724363
30360014.85 –93.18478677
30420017.32 –95.06361113
30480019.79 –91.02766645
692 EMI Receiver Mode Reference
