3 Programming the Analyzer
STATus Subsystem
Questionable Integrity Signal Event Query
This query returns the decimal value of the sum of the bits in the Questionable Integrity Signal Event
register.
The register requires that the associated PTR or NTR filters be set before a condition register bit can set a
bit in the event register. The data in this register is latched until it is queried. Once queried, the register is
cleared.
Mode All
Remote Command
:STATus:QUEStionable:INTegrity:SIGNal[:EVENt]?
Example STAT:QUES:INT:SIGN?
Preset 0
Status Bits/OPC
dependencies
Sequential command
Initial S/W Revision Prior to A.02.00
Questionable Integrity Signal Negative Transition
This command determines which bits in the Questionable Integrity Signal Condition register will set the
corresponding bit in the Questionable Integrity Signal Event register when the condition register bit has a
negative transition (1 to 0). The variable <integer> is the sum of the decimal values of the bits that you want
to enable.
Mode All
Remote Command
:STATus:QUEStionable:INTegrity:SIGNal:NTRansition <integer>
:STATus:QUEStionable:INTegrity:SIGNal:NTRansition?
Example STAT:QUES:INT:SIGN:NTR 4 Burst found will be reported to the Integrity Summary of the Status
Questionable register.
Preset 0
Min 0
Max 32767
Status Bits/OPC
dependencies
Sequential command
Initial S/W Revision Prior to A.02.00
Questionable Integrity Signal Positive Transition
This command determines which bits in the Questionable Integrity Signal Condition register will set the
corresponding bit in the Questionable Integrity Signal Event register when the condition register bit has a
positive transition (0 to 1). The variable <integer> is the sum of the decimal values of the bits that you want
to enable.
EMI Receiver Mode Reference 131
