4 Input/Output Functions
Input/Output
I Skew
Sets the skew factor for the I channel. The skew will shift the channel's data in time. Use this to
compensate for differences in the electrical lengths of the input paths due to cabling.
Key Path
Input/Output, I/Q, I Setup
Remote Command
[:SENSe]:CORRection:IQ[:I]:SKEW <seconds>
[:SENSe]:CORRection:IQ[:I]:SKEW?
Example Delay the data for the I channel by 10 ns.
CORR:IQ:SKEW 10 ns
Preset 0
State Saved Yes
This is unaffected by Preset but is set to the default value on a "Restore Input/Output Defaults" or
"Restore System Defaults->All"
Range 0 s to 100 ns
Min 0 s
Max +100 ns
Initial S/W Revision Prior to A.02.00
I Probe
Access the probe setup parameters for the I channel. See "I/Q Probe Setup" on page 172.
Key Path
Input/Output, I/Q, I Setup
State Saved No
Readback Text [<I port probe id>]
This is reporting the type of probe sensed on the I port. There is no parameter for overriding what is
sensed.
Initial S/W Revision Prior to A.02.00
Attenuation
The attenuation is part of the calibration data stored with the probe type and is initially the value that was
returned by the last calibration. You can modify this value and any changes will be stored with the
calibration data and will survive power cycles and presets. When a probe calibration is performed the
attenuation value will be overwritten by the calibration.
Key Path
Input/Output, I/Q, I Setup | Q Setup, I Probe | Q Probe
Remote Command
[:SENSe]:CORRection:IQ:I|Q:ATTenuation:RATio <real>
[:SENSe]:CORRection:IQ:I|Q:ATTenuation:RATio?
Example Set the attenuation for the current I probe to 100.00:1.
CORR:IQ:I:ATT:RAT 100
164 EMI Receiver Mode Reference
