10 Monitor Spectrum Measurement
BW
10 MHz 10 kHz – 100 kHz
5 MHz 10 kHz – 100 kHz
2 MHz 1 kHz – 10 kHz
1 MHz 1 kHz – 10 kHz
500 kHz 300 Hz – 3 kHz
200 kHz 100 Hz – 1 kHz
100 kHz 100 Hz – 1 kHz
50 kHz 30 Hz – 300 Hz
20 kHz 10 Hz – 100 Hz
10 kHz 10 Hz – 100 Hz
5 kHz 10 Hz – 30 Hz
2 kHz 10 Hz – 30 Hz
1 kHz 10 Hz – 30 Hz
Preset 10 kHz
State Saved Saved in instrument state
Min 10 Hz
Max 100 kHz
Default Unit Hz
Backwards
Compatibility SCPI
:SENSe1|SENSe2|[SENSe]:BANDwidth|BWIDth:IF
Backwards Compatibility
SCPI Notes
This command above is included for ESU compatibility. The suffix 1|2 is irrelevant to the
measurement, they are added solely for remote language compatibility.
Initial S/W Revision A.13.00
750 EMI Receiver Mode Reference
