❈ The actual engine room in the vehicle may differ from the illustration.
OJF075139L/OJF075141L
Gasoline Engine (THETA 2.4L - MPI)
Gasoline Engine (THETA 2.4L - GDI)
1. Engine coolant reservoir
2. Engine oil filler cap
3. Brake/Clutch fluid reservoir (if
equipped)
4. Air cleaner
5. Fuse box
6. Negative battery terminal
7. Positive battery terminal
8. Engine oil dipstick
9. Radiator cap
10. Windshield washer fluid reservoir
8-05
8
Maintenance
