❈ The actual shape may differ from the illustration.
OJF075001L/OJF075003L
Gasoline Engine (THETA 2.0L T-GDI)
Diesel Engine (U2 1.7)
1. Engine coolant reservoir
2. Engine oil filler cap
3. Brake/Clutch fluid reservoir (if
equipped)
4. Air cleaner
5. Fuse box
6. Negative battery terminal
7. Positive battery terminal
8. Engine oil dipstick
9. Radiator cap
10. Windshield washer fluid reservoir
Maintenance
8-06
