Chapter 9 List of FD5P motor controller parameters
User Manual
See chapter 6.1, table 6-2
See chapter 6.1, table 6-2
See chapter 6.1, table 6-2
Operation mode channel 0: select via
input port
Operation mode channel 1: select via
input port
See chapter 6.2.1, table 6-8
unit: rpm
See chapter 6.2.1, table 6-8
unit: rpm
See chapter 6.2.1, table 6-8
unit: rpm
See chapter 6.2.1, table 6-8
unit: rpm
Numerator of electronic gear
Denominator of electronic Gear
Pulse control mode 0: CW / CCW mode
1: pulse direction mode
2: incremental encoder mode
Filter parameter of pulse input
Maximum frequency of input pulse
unit: pulse/ms
Target (position velocity) reached
time window. unit: ms
Target (position velocity) reached
time window. unit: ms
Multi-
stage_pos_control_L
Select the internal position segment, When
the data is 0~7, it means to select and set
the DIN position 0~7 in turn.
When the data is 8, it means homing offsets
in sequence.
D3.40 Selected position L
Number of pulses=M*10000+N
When the "Drive Enable" function is
configured to Din, the "Control word"
(6040.00) is set to this value when the
corresponding Din valid input is 1.
