KDC User Manual SYNCHRONIZATION
161
transmission of collected barcodes. Some Windows applications, such as Excel, require longer
delay times.
Attachments
Timestamp, Barcode Type, and Serial Number may be attached to the scanned barcode by
selecting these options. The Serial Number of the KDC may be attached to the Start or End of
Record.
Prefix and Suffix
⚫ Enter the characters the user wants to attach to the front (Prefix) or back (Suffix) of the
barcode in the Prefix and Suffix fields.
⚫ The character set is any combination of ASCII characters including alphanumeric, line
feed (“\n”), and carriage return (“\r”).
Order and Delimiter
⚫ Select Order of Data – Type, Data, and Timestamp
⚫ Select the Delimiter between Data – Tab, Space, Comma, and Semicolon
⚫ Select the Delimiter between Records – None, LF, CR, Tab, and <LF & CR>
Application Options
Synchronize Non-Compliant Data
The KDC will synchronize both compliant and non-compliant data (filtered data) if Synchronize
Non-Compliant Data option is Enabled.
Consolidate Steps in One Record
KTSync will consolidate the data collected in Step 1 with the data collected in Step 2 and/or
Step 3. When Consolidate Steps in One Record is enabled, data will be consolidated into one
record instead of individual data records for each step. If this option is enabled, non-complete
records, i.e. three steps were defined but data was only collected for two steps, will be
discarded.
Attach Quantity
If this option is enabled, quantity will be attached to the left or right of the data.
