DB Lookup Application
The DB Lookup application enables the user to download a database to the KDC that may
then be utilized for advanced AUTO-ID applications, such as displaying additional data after
scanning a barcode. For example, using our DB Lookup application, you may download a
product database including information such as description, price, and stock quantity. With
the advanced data functionality built-in to the KDC, you may easily display product price,
description, and stock level after the product’s barcode is scanned.
Functionality of DB Lookup Application (based on the firmware version v2.86 and v3.0+)
⚫ The database size may not exceed 800 records (v2.86) / 61,440 records (v3.0+).
⚫ The maximum record size is 128 bytes.
⚫ Each record may have up to 4 fields, including the barcode, which is the primary key.
⚫ The maximum field size is 39 characters.
⚫ Quantities may be entered by pressing the UP or DOWN scroll buttons after DB fields
are displayed.
⚫ Quantity may be 1 to 128.
⚫ The user may create a database using Microsoft Excel.
1. Excel file must be saved as .txt.
2. Records should be separated by CR/LF.
3. Fields should be separated by TAB.
4. Database should end with CR/LF.
5. Last 4 bytes of database should be CR/LF/CR/LF.
DB Lookup Fields and Settings (based on the firmware version v2.86 and v3.0+)
⚫ Download DB to KDC - Downloads user created database to KDC.
⚫ Starting Quantity - Enter predefined start quantity for each scanned barcode. The
start quantity may be defined from 1 to 128 and may be adjusted using UP or DOWN
buttons.
⚫ Barcode Field - Select the position of barcode field in database from 1 to 4.
⚫ Stored Barcode Start Position - Select the numeric position of start substring character
of barcode in database from 1 to 39.
⚫ Scanned Barcode Start Position - Select the numeric position of start substring
character of scanned barcode from 1 to 39.
