KDC User Manual BLUETOOTH
49
Charge KDC Battery
Prior to using the KDC, the user should charge the battery. Follow the instructions below.
1. Connect the KDC cable to the mini USB connector on the KDC.
2. Connect the KDC cable to the Type A USB connector on the computer.
3. The KDC battery will begin charging. Within a few minutes, the two small LEDs (three
LEDs in case of KDC500) on the front panel will illuminate orange. When the battery is
fully charged, the LEDs will illuminate green.
Configure KDC
The KDC is designed to meet the data collection requirements of many different industries in a
variety of dynamic situations. To deliver the best performance in these diverse environments,
the KDC is designed to be configured quickly and easily.
However, to perform at its optimum level, the KDC must be configured properly. Until the user
is familiar with the KDC configuration settings, it is recommended that the user DOES NOT
modify the KDC settings. The KDC may be configured by using three different methods, which
are explained in Section 3.3 – KDC Menus, Chapter 5 –Synchronization, and Appendix C/D –
Special Barcodes.
CONFIGURATION METHODS FOR THE KDC100/200/250/270/280/300/350/500
⚫ KDC Menu
⚫ KTSync Software
⚫ Special Barcodes
Figure 11 - Location of KDC Menu and use of buttons (KDC100/200/250/270/280/300)
KDC100
KDC20/200
KDC30/250/300/270/280
KDC350
KDC400/470
KDC500
2 Hours
2 Hours
3 Hours
4 Hours
4 Hours
4 Hours
Table 2 - Number of hours required to fully charge a KDC Battery
Select one of the
menus by pressing
the Scan Button.
Press the Up and DOWN
Buttons simultaneously to
access the KDC menu.
Move the menu bar up and
down by pressing Up and
Down Buttons.
