KDC User Manual BLUETOOTH
95
Data Format
Specify the data format of UHF data when it is transmitted from KDC to Host.
⚫ Options: Binary / Hexa Decimal
Smart Hopping
It enables KDC450U to find an optimized UHF channel and can be initiated by reading a special
barcode.
WIFI Config Menu (KDC350F)
KDC350F WiFi model can send and receive data to/from host by using the following protocols.
⚫ UDP
⚫ TCP
⚫ HTTP_GET
⚫ HTTP_POST
In UDP/TCP mode, KDC350F will support full duplex mode, meaning is the KDC350F will be
ready to get data from host all the time.
Power
⚫ Turns the Wi-Fi Module Power ON and OFF.
AP
⚫ Set AP SSID.
⚫ Set AP Passcode.
Server
⚫ Configure the following server information
◼ IP Address
◼ URL Address
◼ Port Number
◼ Protocol (UDP/TCP/HTTP-GET/HTTP-POST)
◼ SSL(Security)
◼ Server Page
Connect
⚫ Connect to AP and server.
