KDC400/450/470 Barcode Reader and Data Collector

Keypad

Shift Button

Green/Red/Orange LEDs

UP Button

DOWN Button

SCAN Button

Ultra-mini USB Port

KDC350

Menu Button

Mode Button

Function Button

KDC400/450
