Komatsu 930E-2 - Circuit Breakers

CIRCUIT BREAKERS
AMPS DEVICE(S) PROTECTED CIRCUIT LOCATION
CB00 50 12 Volt Power Source 11B1 Battery Control Box
CB1 5 Fan Clutch Power 440 Electrical Interface Cabinet
CB2 20 ECM Main Power 240M Electrical Interface Cabinet
CB3 20 ECM Main Power 241M Electrical Interface Cabinet
CB4 20 ECM Rec. Power 240R1 Electrical Interface Cabinet
CB5 20 ECM Rec. Power 241R1 Electrical Interface Cabinet
CB6 15 Engine Service Lights 11SL Electrical Interface Cabinet
CB7 10 Lincoln Lube Solenoids 68 Electrical Interface Cabinet
CB8 10 Body-up Limit Switch/Solenoid 712H Electrical Interface Cabinet
CB9 10 Spare Electrical Interface Cabinet
CB10 10 Spare Electrical Interface Cabinet
CB11 15 Spare Electrical Interface Cabinet
CB12 5 Spare Electrical Interface Cabinet
CB13 15 Clearance Lights 11CL RB1, Elect. Interface Cabinet
CB14 15 Turn Signals 11Z RB1, Elect. Interface Cabinet
CB15 15 RD1, RD2, & Tail Lights 41T RB1, Elect. Interface Cabinet
CB16 15 Dynamic Retard Lights 44C RB3, Elect. Interface Cabinet
CB17 15 Manual Back-up Lights 47B RB3, Elect. Interface Cabinet
CB18 15 Stop Lights 44A RB3, Elect. Interface Cabinet
CB19 15 Back-up Horn 79A RB3, Elect. Interface Cabinet
CB20 5 439E Circuit & Park Brake Fail Relay Coil 439E RB4, Elect. Interface Cabinet
CB21 15 Steering Bleeddown, Horn 11A RB4, Elect. Interface Cabinet
CB22 5 Relay Board RB6, K2 coil (Engine Run/Ignition) 23D RB4, Elect. Interface Cabinet
CB23 15 Low Beam Headlight, L.H. 11DL RB5, Elect. Interface Cabinet
CB24 15 Low Beam Headlight, R.H. 11DR RB5, Elect. Interface Cabinet
CB25 15 High Beam Headlight, L.H. 11HL RB5, Elect. Interface Cabinet
CB26 15 High Beam Headlight, R.H. 11HR RB5, Elect. Interface Cabinet
CB27 15 Headlight Switch 11D RB5, Elect. Interface Cabinet
CB28 15 Payload Meter 39J RB2, Elect. Interface Cabinet
CB29 15 Payload Meter 39G RB2, Elect. Interface Cabinet
CB30 15 Hazard Light Switch 11L Power Distribution Module
CB31 15 Cab Heater/AC Blower Motor 12H Power Distribution Module
CB32 15 Warning Lights, A.I.D. Module 12M Power Distribution Module
CB33 Not Used Power Distribution Module
CB34 Not Used Power Distribution Module
CB35 Not Used Power Distribution Module
CB36 10 Cigar Lighter 11B2 Power Distribution Module
CB37 10 Windshield Washer & Wiper 712W Power Distribution Module
CB38 5 Fuel, Engine Temperature, Oil Pressure, Voltmeter Gauges 712D Power Distribution Module
CB39 Not Used Power Distribution Module
CB40A 5 Accessory Plug (12VDC) 12GE Power Distribution Module
CB40B 10 Radio/Cassette Player 11B4 Power Distribution Module
CB41A 15 Cab Door Window, L.H. 11B6 Power Distribution Module
CB41B 15 Cab Door Window, R.H. 11B7 Power Distribution Module
CB42 15 Air Seat 712A Power Distribution Module
CB43 10 Start Signal 21S Power Distribution Module
CB50 20 Communications Radio SPR42/SPR46 Power Distribution Module
CB51 20 Dispatch Radio SPR43/SPR47 Power Distribution Module
CB52 10 Spare SPR44 Power Distribution Module
D03019 04/01 24VDC System Components D3-15
