Engine Operation
Total Payload and Total Number of Cycles
The total payload and overall number of cycles can be displayed using the forced display operation. Both values
start from a zero point whenever the memory has been cleared. The payload total is automatically displayed when
the load is dumped.
Other Data
ITEM UNIT RANGE REMARKS
Number when Canceled Number 1 - 65535
Every time the engine is started
the number advances by one.
Last Two Digits Of Year Year 0 - 99
Month Month 1 - 12
Day Day 1 - 31
Time Hour Hour 24 Hour Clock
Time Minute Minute 0 - 59
NOTE: If the engine operation number is a 0, this indicates that the problem occurred or was canceled (depends on
the operation that was performed) when the key switch was in the ON position and the engine was not running.
CONTENT ITEM UNIT RANGE REMARKS
Set Up Data That The
Operator Can Check
Speed Limit Km/MPH 0 - 99
Option Code Digital Number 0 - 13 Communication Mode
Calibration Data
Year Year 0 - 99
Date and time when calibrated.
Month Month 1 - 12
Day Day 1 - 31
Hour Hour 24 Hour Clock
Minute Minute 0 - 59
ITEM UNIT RANGE REMARKS
Total Payload
Metric Tons
Short Tons
0 - 999900.0
The total payload since the unit
was cleared.
Total Number Of Cycles Digital Number 0 - 9999
The number of cycles since the
unit was cleared.
Last Two Digits Of Year Year 0 - 99
Date and time the unit was
cleared.
Month Month 1 - 12
Day Day 1 - 31
Time Hour Hour 24 Hour Clock
Time Minute Minute 0 - 59
M20007 10/00 Payload Meter II M20-11
