TYPES OF DATA STORED
Cycle Data
One cycle is considered to be from the point where a load is dumped to the point where the next load is dumped.
Data between these two points is recorded in memory. Examples of the data are shown below. The maximum
number of cycles that can be stored in memory is 2900 cycles.
ITEM UNIT RANGE REMARKS
Engine Operation Number Number 1 - 65535
Advances by one each time the
engine is started.
Month Month 1 - 12
Day Day 1 - 31
Time Hour Hour 24 Hour Clock
These values are stored when the
load is dumped.
Time Minute Minute 1 - 59
Payload
Metric tons
Short tons
0 - 6553.5
Travel Time When Empty Minute 0 - 6553.5
Travel Distance When Empty Miles/Km 0 - 25.5
Maximum Travel Speed When Empty Mph/Kmh 0 - 99
Average Travel Speed When Empty Mph/Kmh 0 - 99
Time Stopped When Empty Minute 0 - 6553.5
Time Stopped During Loading Minute 0 - 6553.5
Travel Time When Loaded Minute 0 - 6553.5
Travel Distance When Loaded Miles/Km 0 - 25.5
Maximum Travel Speed When Loaded Mph/Kmh 0 - 99
Average Travel Speed When Loaded Mph/Kmh 0 - 99
Time Stopped When Loaded Minute 0 - 6553.5
Dumping Time Minute 0 - 6553.5
Speed Limit Mph/Kmh 0 - 99
Warnings For Each Cycle The fault codes that occur during each cycle
M20007 10/00 Payload Meter II M20-9
