All propulsion system power cables must be prop-
erly secured in their wood or other non-ferrous
cable cleats. If clamps are cracked or broken, re-
place them with new parts. Inspect cable insula-
tion and replace entire cable if insulation is
damaged.
5. Connect Brake apply line (11) to port on brake
assembly back plate.
6. Using new O-rings, install brake cooling lines.
7. Seal gap around brake cooling hoses (see sealant
specification below) where cooling hoses pass
through spindle holes. Install clamps (3).
NOTE: Brake system hoses must be sealed where
they pass through axle spindle holes to prevent cooling
air loss.
8. Connect air sensor hose, if removed. Install park
brake apply hose (13).
9. Install inspection covers on access holes (17).
10. Install air duct (5). Close duct inspection covers
and install duct tube in rear opening of axle hous-
ing.
11. Open pump shut-off valves.
12. Check wheel motor oil level. Check hydraulic tank
oil level before and after engine start-up and brake
bleeding procedure. Service as necessary.
13. Bleed the brake apply line according to the instruc-
tions in “Wet Disc Brake Assembly, Brake Bleed-
ing Procedure”, Section “J”.
14. Remove temporary capscrews previously installed
in wheel motor transmission housing mounting
flange. Install tires and rims using procedures
outlined earlier in this section.
15. Raise truck, remove support stands. Lower truck
and remove jack.
MASTIC SEALANT
Vendor Product Name:
• Uniseal 310S Sealant
Description:
• 2.00 in wide x .125 in. thick x 120 in. long roll
Vendor Source:
• Uniseal
1800 W. Maryland Street
Evansville, IN 47712
• Other sources may be available throughout
the world.
G5-6 Rear Axle Housing 9/99 G05015
