Engine ON/OFF Data
When the engine is started or stopped, the following data is recorded.
Fault Codes and Warning Data
ITEM UNIT RANGE REMARKS
Engine Operation Number Number 1 - 65535
Advances by one each time the
engine is started.
Last Two Digits Of The Year Year 0 - 99
Indicates when the engine was
started.
Month Month 1 - 12
Day Day 1 - 31
Time Hour Hour 24 Hour Clock
Time Minute Minute 0 - 59
Last Two Digits Of The Year Year 0 - 99
Indicates when the engine was
shut off.
Month Month 1 - 12
Day Day 1 - 31
Time Hour Hour 24 Hour Clock
Time Minute Minute 0 - 59
Total Payload
Metric tons
Short tons
0 - 999900.0
Total payload from the time when
the engine was started until the
time the engine was shut off.
Total Number Of Cycles Number 0 - 9999
Totals for the time that the engine
was running.
The engine operation numbers are included in the fault and warning data.
ITEM UNIT RANGE REMARKS
Error Code
Displayed by a combination of letters and numbers representing a specific
error code.
Engine Operation Number
At Time Of Occurrence
Number 1 - 65535
Every time the engine is started
the number advances by one.
Number Of Times Of Occurrence Since
The Engine Was Switched ON
Number 1 - 255
Last Two Digits Of Year Year 0 - 99
Month Month 1 - 12
Day Day 1 -31
Time Hour Hour 24 Hour Clock
Time Minute Minute 0 - 59
M20-10 Payload Meter II M20007 10/00
